Fax: 519-782-3139 or 1-800-728-6324 Email:
FLEXIBLE POND LINER
EPDM Pond Liner
45 mil
Properties:
Black, 20 Year Pro-Rated Warranty,
UV and Air Pollution Resistant, Flexible and
Elastic, Safe for Fish
It’s What You Can’t See….
That Really Counts.
Cut to length:
Up to 100' in the following widths:
5.5', 15', 20' or 25'
Up to 50' in 30' width
$0.89 per sq. ft.
Liners available for Pick-up or Delivery.
Note:
Liners exceeding 485 sq. ft. must be shipped by Truck Freight.
Please call for rates.
Shipped liners may be subject to a $23.00 handling charge.
Calculating the Correct Size of Liner Required
Width:
Maximum Width of Pond + (2 x Maximum Depth of Pond) + 2' overlap
Length:
Maximum Length of Pond + (2 x Maximum Depth of Pond) + 2' overlap
Disregard shelves when measuring
Example:
Pond Size 6' x 8' x 3' deep
Width: 6 + (2 x 3) + 2 = 14' Length: 8 + (2 x 3) + 2 = 16' The liner size required is 15' x 16'.
For instructions on installation see page 39-40.
See page 40 for finishing edges.
Geotextile Felt Underlay
Protects liner from punctures.
15' width $0.32 per sq. ft.
EPDM Patch Tape
Easy and effective way to patch.
6" wide $4.99 per ft.
Double-Sided Tape
For bonding two liners.
3" wide $1.99 per ft.
